TERMOSTUFA A PELLET | PELLET THERMOSTOVE

GLENDA

 TERMOSTUFA A PELLET | Pellet thermostove

GLENDA nuovo design ed evoluzione di un termoprodotto affidabile e performante. Già predisposta per il dialogo con sistemi domotici. Alto rendimento e basse emissioni. Facilità di accesso e manutenzione. A richiesta con sistema di produzione di acqua calda sanitaria. Dotazioni: cronotermostato, vaso di espansione, circolatore, jolly e valvola di sicurezza.

GLENDA new design and evolution of a reliable and performing thermo-product. Already set up for dialogue with home automation systems. High efficiency and low emissions. Ease of access and maintenance. On request with domestic hot water production system. Equipment: chronothermostat, expansion tank, circulator, jolly and safety valve.

     11,3 – 25,5 kW *

    MAX. 91,5 / MIN. 93  %

     Pellet 35 Kg

     (LxPxH):  580x670x1138 mm

     210 Kg

* Potenza chimica al focolare | Heat output



 0508
Rosso/Red
0000
Bianco/White



  Detrazione fiscale 50% per ristrutturazione edilizia (BONUS CASA)

Descrizione

Volumi di ambienti ben isolati | Volume of well-insulated environments
m3 613

Potenza Termica Focolare MIN- MAX. | Heat output
kW 11,3 – 25,5

Potenza Termica Utile MAX. (Pot. Nominale) | Nominal power output
kW 23,3

Potenza Utile MIN. /MAX. all’acqua | Water heating power min – max
kW 8,8 – 20,7

Potenza Utile MIN -MAX. all’ambiente | Heating environment power min – max
kW 1,7 – 2,6

Potenza Termica Utile MIN. (Pot. Ridotta) | Nominal power output
kW 10,5

Rendimento a: Potenza MIN – Potenza MAX. | Efficency

MAX. 91,5 / MIN. 93  %

Capacità serbatoio pellet | Pellets storage capacity
kg 35

Consumo Combustibile | Fuel consumption

min. 2,30/max 5,20 kg/h

Ventilatori aria riscaldamento| Air heating fans
No

Scarico fumi | Exhaust fumes
Ø mm 80

Aspirazione aria | Air aspiration
Ø mm 50

Produzione Acqua Sanitaria | Hot Water production
NO

Capacità Caldaia | Water capacity boiler
29 L

Dimensioni | Dimensions
LxPxH mm 580x670x1138

Rivestimento | Cladding

Acciaio verniciato

Peso | Weight
kg 210

  • LIBRETTO TECNICO | Using instructions
  • CERTIFICATO AMBIENTALE | Environmental certificate
  • CERTIFICATO CE | CE certificate
  • DICHIARAZIONE DI CONFORMITÀ CONTO TERMICO | Declaration of conformity
  • ETICHETTA ENERGETICA | Energy Label
  • SCHEDA PRESTAZ. ENERGETICA
  • DICHIARAZIONE DI CONFORMITÀ (DOC) | Declaration of conformity
  • DICHIARAZIONE DI PRESTAZIONE (DOP) | Declaration of performance
  • CERTIFICAZIONE ARIAPULITA | AriaPulita certificate
  • LOGO ARIAPULITA

Informazioni aggiuntive

Colore

, ,

Combustibile

Pellet

Potenza

19 kW

Tipologia

Linea Hydro / Hydro Line
